FLEOR 4 Band Acoustic Guitar EQ Equalizer Piezo Pickup EQ-7545R (Curved)

Vendor
FLEOR
Regular price
$12.00
Sale price
$12.00
Regular price
$18.00
Sold out
Unit price
per
Shipping calculated at checkout.

Features:

  • 100% Brand New and High Quality!

  • 4 Bands EQ-7545R pick up equalizer system perfect for standard acoustic guitar or cigar box guitar.

  • Curved plastic surface fits the curved side of a standard acoustic guitar.

  • 4 Bands (Bass/Middle/Treble/Presence ) plus volume control,built-in battery holder for 9-volt battery (not included), low battery indicator.

  • The rod piezo ceramic pick-up offers great tone and pickup range, and is made to be mounted beneath the saddle of a standard acoustic guitar, but it can be easily built into a cigar box guitar bridge as well.

  • Pre-wired for easy assembly,connecting wire with 6.35mm(1/4 inch) output jack.


Specifications:

  • Features:4 Band EQ.

  • Surface:Curved surface.

  • Color: Black with white numbers.

  • Input Impedance: 2.2MΩ.

  • Frequency Response: 20Hz-20KHz.

  • Bass: [+12dB at 60Hz]

  • Middle: [+12dB at 600Hz]

  • Treble: [+12dB at 2.2KHz]

  • Presence: [+12dB at 8KHz]

  • Power Supply:9V Alkaline Battery (Not included).

  • Low Battery Check S/W.

  • Function: Master Volume.

  • 6.35mm(1/4") Output Jack.

  • Pick-up: Piezo ceramic pick-up.

  • Dimension: W 46mm X H 103mm(1.8" X 4.1").


Packing List:

  • 1 x 7545R EQ Equalizer

  • 1 x Piezo ceramic pick-up

  • 1 x Mounting base with sticker

  • 4 x Mounting screws

  • 1 x Nut

  • 1 x Washer

  • 1 x Cable Tie
